01 — Hero / Product 04
04

Automation built for factories that change.

Modular robotic work cells designed to be reconfigured as production demands evolve. Not a fixed line — a system you can move, expand, and retask.

Payload
35 kg
Reach
1,850 mm
Repeatability
±0.05 mm
Fig. 01 — Work envelopeScale: 1:25
6-axis configuration — Modular deployment. Work envelope in plan view. Repeatability at tool flange under standard conditions.
KF System Diagram 04-A Revision 03 — 2026
View specifications Request cell info
02 — Product overview
Cell 04 is a
work cell,
not a line.
Designed for shops that run
multiple parts, short runs,
and shifting schedules.
KF
Base frame
anchored — not poured

Build for change, not for one part.

Most automation is specified for a single product at a single volume. Cell 04 is specified for change: same base frame, same controls, different tooling. Move it, re-tool it, keep producing.

“If the factory changes next quarter, the cell should change with it — without rebuilding the line.”

The 6-axis arm provides the reach and repeatability for machine tending, welding, and assembly, while the modular base lets you reconfigure fixtures and fencing as jobs evolve.

Machine tending Assembly Welding prep
Technical specifications KF / CELL 04 — Rev. 03
Payload35 kg
Reach1,850 mm
Repeatability±0.05 mm
Configuration6-axis
DeploymentModular
ModelKF / CELL 04
Only supplied specifications shown— KF Engineering
Industrial robotic work cell on factory floor — handling equipment
Cell 04 — Floor viewDetroit pilot install
Specimen photograph. Not a rendering of final delivered configuration — layout adapts to site.
Payload tested at full reach 35 KG
03 — Capabilities

Three
reasons
it stays
in use.

Not features for a brochure.
Behaviors that survive
a schedule change.

01 / Reconfigure

Re-tool without
rebuilding

Base frame, fencing, and fixtures detach and reposition. Swap end-of-arm tooling and re-teach points. The cell moves with the job.

Fixture grid / Tool-agnostic flange / Quick fence release
02 / Integrate

Fit the shop
you have

Anchored frame on existing slab. Standard safety and controls interface with your machines. No poured foundation, no dedicated line.

Floor-anchored / Standard I/O / Modular safety
03 / Operate

Run it with
the team on hand

Teach pendant and templated programs for common tasks. Operators retask the cell between runs — no specialist required on shift.

Templated jobs / Pendant teach / Shift-level retask

04 — Deployment

A cell you can live with, then live without moving walls.
01
Assess
We map your parts, fixtures, and machine interfaces on site.
02
Configure
Cell 04 kitted: arm, base, fencing, fixtures, controls.
03
Deploy
Anchor, connect, teach. Run pilot parts same week.
Timeline varies by application. No performance guarantees beyond supplied specs.
Process — From floor study to first part

Move it again
when the mix
changes.

Because deployment is modular, redeployment is part of the design. If volume shifts or a new part takes priority, the same cell reconfigures for the next run.

Week 01
Floor study

Interfaces, clearances, safety zones mapped.

Week 02–03
Cell kitting

Base frame and tooling staged per job.

Week 04
Pilot run

First article, adjustments, handover.

Reach envelope1,850 MM
Full extension at 35 kg — see spec sheet
PrecisionRepeatability
±0.05mm — at tool flange
6-axis configuration — modular deployment keeps calibration on site.
Note
Only specifications in the spec sheet are warranted. No additional certifications or performance data claimed.
05 — Contact
Tell us the part, the volume, and the machine. We'll tell you if Cell 04 fits — and how it would sit on your floor.
Response within one
business day. Floor
review available.
Kinetic Foundry — Let's place a cell
Put 04
on your
floor.

Modular means you don't commit the building. Start with one cell, prove the changeover, add or move as the mix evolves.

Request cell info Download spec sheet
Contact — Detroit
Emailhello@kineticfoundry.co
Phone+1 (313) 555-0140
BaseDetroit — Great Lakes
Cell availability
KF / CELL 04 — Available Q4 2026
Configuration: 6-axis / 35 kg / 1,850 mm / ±0.05 mm
Only specifications above are claimed. No customers, certifications, or statistics implied beyond listed data.
